CSiXCAD v21 is a CAD drawing generation plugin that allows you to bring your structural models into AutoCAD (and compatible CAD platforms) faster and more efficiently. It integrates with structural analysis software such as ETABS, SAP2000, and SAFE, helping to accelerate the production of drawings and technical documentation.
Key features
• CAD-based documentation export and generation from the structural model.
• Faster workflow for drawings, details, and project documentation.
• Ideal for teams that need to reduce drawing time and maintain consistency between model and drawings.
Ideal for
• Structural engineers and designers.
• Engineering firms working with ETABS / SAP2000 / SAFE and requiring CAD documentation.
• Companies looking to optimize the delivery of technical drawings and details.
Minimum requirements for installing CSiXCAD v21 (Windows)
• Operating system: Windows 10/11 (64-bit)
• Processor: Intel Pentium 4 / AMD Athlon 64 minimum (recommended Intel i5/i7 or Ryzen or higher)
• RAM: 4 GB minimum (recommended 8 GB+)
• Storage: 6 GB free for installation (recommended SSD and more space depending on projects)
• Graphics: minimum resolution 1024×768 (recommended dedicated GPU with 512 MB+ for better performance)
• Base software: requires a compatible CAD platform installed (e.g., AutoCAD or compatible equivalent)
• Internet: recommended for updates and activation (depending on license)
Specifications may vary depending on the size and complexity of the project. For simple tasks, requirements may be lower.
Difference between alternative license and original license
• Alternative license (non-original): one-time payment, more economical, perpetual, direct installation and activation on the computer, not a serial number, does not use an account or subscription.
• Original license: activation with serial number, traditional activation method.
Note: These licenses are not transferable; once installed/activated on a computer, it only works on that same computer and cannot be transferred to another.
